Combining membrane filtration and flocculation for microalgae harvesting

Water Research
Water Research

The research article 'Combining patterned membrane filtration and flocculation for economical microalgae harvesting' has been published in Water Research.


Membranes have a lot of potential for harvesting microalgae, but mainly membrane fouling and high harvesting costs linked to low fluxes are hampering their breakthrough. Patterned membranes can reduce fouling by enchancing local turbulences close to the membrane surface on one hand, and by increasing the active area per m2 of installed membrane on the other. Flocculation can further increase membrane permeance by increasing microalgal partical size and reducing the fraction of free organic matter in the feed. In current study, the effect of polyethylene glycol (PEG) in the casting solution of patterned polysulfone membranes was investigated to better tune the performance of the patterned membranes, together with the effects of cross-flow velocity and chitosan dosage on membrane fouling. The energy consumption and total harvesting cost, extrapolated to a full-scale microalgal harvesting, were then estimated. The patterned membrane prepared with a 28w% PEG concentration showed the highest clean water permeance (900±22 L/m2 h bar) and membrane permeance in a microalgal suspension (590±17 L/m2 h bar). Patterned membranes showed a lower filtration resistance (15% permeance decline at the end of filtration) than flat membranes (72%) at a cross-flow velocity of 0.0025 m/s. Increasing cross-flow velocity could increase membrane permeance in most cases. The highest stable membrane permeance (110±17 L/m2 h bar) and the lowest filtration resistance were achieved when combining patterned membrane filtration with flocculation at optimized chitosan dosage. A very low energy consumption (0.28 kWh/kg) and harvesting cost (0.16 €/kg) were achieved under these conditions.

Access the complete article on ScienceDirect.
